New NSPV EC1A Junction Box IP65 & IP67 1

New NSPV EC1A Junction Box IP65 & IP67 2

New NSPV EC1A Junction Box IP65 & IP67 3

New NSPV EC1A Junction Box IP65 & IP67 4

New NSPV EC1A Junction Box IP65 & IP67 5

New NSPV EC1A Junction Box IP65 & IP67 6

New NSPV EC1A Junction Box IP65 & IP67 7

New NSPV EC1A Junction Box IP65 & IP67

Accepting DC1000V & DC1500V both,
With caps IP65
With Plug Connectors IP67
EC1AF Female & EC1AM Male
contact resistance ≤0.25 mΩ, with IEC62852.
Connecting system: Soldering for Ribbon Plug-in for connector

Inquiry

Write a Review

Product Introduction

The NSPV Brand New Solar PV Panel EC1A junction box is a top-tier component designed to optimize solar photovoltaic systems. Boasting an IP65 rating for DC 1000V and an IP67 rating for DC 1500V, it offers exceptional protection against dust and water, ensuring reliable performance even in harsh environments. With a typical contact resistance of ≤0.25 mΩ, it minimizes power loss, enhancing overall system efficiency.

Crafted from PA/CU materials, this junction box exhibits excellent UV and water resistance, prolonging its lifespan and reducing maintenance costs. Its NSPV Brand design negative positive configuration simplifies installation, saving both time and labor expenses.

Moreover, the TUV IEC62852 certification guarantees its adherence to international safety standards, providing peace of mind regarding system safety. By choosing the NSPV EC1A junction box, users can enjoy significant cost savings through reduced maintenance and enhanced efficiency, while also benefiting from its superior safety features and durability.

Product Specifications

IP Rating	IP65 for DC 1000V; IP67 for DC 1500V
Rated Voltage	DC 1000V (IP65), DC 1500V (IP67)
Typical Contact Resistance	≤0.25 mΩ
Material	PA/CU (Polyamide/Copper)
Design	Negative Positive (NSPV Brand design)
Certification	TUV IEC62852 compliant

Our Features

The NSPV Brand New Solar PV Panel EC1A junction box is a cutting-edge component designed to enhance the efficiency and safety of solar photovoltaic systems. Featuring an IP65 rating for the DC 1000V model and an IP67 rating for the DC 1500V model, this junction box provides robust protection against dust and water ingress, ensuring reliable performance in various environmental conditions. The design incorporates a negative positive (NSPV Brand design) configuration, which simplifies installation and enhances system compatibility. The junction box is crafted using high-quality PA/CU materials, ensuring durability and longevity.

Our Advantages

Dual Voltage Compatibility: Accepts both DC1000V and DC1500V.
High IP Rating for Caps: Caps feature an IP65 rating for dust and water resistance.
Waterproof Plug Connectors: Plug connectors are rated IP67 for enhanced waterproofing.
Gender-Specific Design: Includes EC1AF female and EC1AM male connectors for precise matching.
Low Contact Resistance: Contact resistance is ≤0.25 mΩ, meeting IEC62852 standards.
Flexible Connection System: Supports soldering for ribbon and plug-in for connectors.

Application

The NSPV EC1A junction box is suitable for a wide range of solar photovoltaic applications, including residential rooftop systems, commercial solar farms, and industrial solar installations. Its high voltage ratings make it compatible with modern high-efficiency solar panels, allowing for greater flexibility in system design. The robust construction and superior protection features make it an excellent choice for installations in harsh environments, such as coastal areas or regions with extreme weather conditions.

FAQ

What is the main difference between the IP65 and IP67 rated models?

The main difference lies in their level of protection against water ingress. The IP65 rated model is protected against low-pressure water jets, while the IP67 rated model can withstand temporary immersion in water up to 1 meter deep.

Can the NSPV EC1A junction box be used with any solar panel?

The NSPV EC1A junction box is designed to be compatible with a wide range of solar panels. However, it is essential to ensure that the voltage rating of the junction box matches or exceeds the voltage of the solar panel to ensure safe and efficient operation.

What certifications does the NSPV EC1A junction box have?

The NSPV EC1A junction box is TUV IEC62852 compliant, ensuring that it meets international safety and quality standards for solar photovoltaic components. In conclusion, the NSPV Brand New Solar PV Panel EC1A junction box is a high-performance, reliable component that enhances the efficiency and safety of solar photovoltaic systems. Its superior features, specifications, and advantages make it an excellent choice for a wide range of solar applications.
