Pole Number: 5 Pins

Rated current: Max.40A(6sqmm)

Rated voltage: 500V AC

Degree of protection: IP67 Waterproof
Suitable cable cross sections: 1.5~6sqmm or 16~10AWG
Connector Verson: AC 5C Connector I verson

Inquiry

Write a Review

Product Introduction

The NSPV 5C Solar AC Connector 5 Pins, with an IP67 rating, is a top-tier choice for solar energy systems. Rated for a maximum current of 35A (6sqmm) and a voltage of 500V AC, it ensures reliable and efficient power transmission. Its typical contact resistance of ≤0.25 mΩ minimizes energy loss, enhancing system efficiency.

Constructed from durable PPE/PA materials, this connector withstands harsh environmental conditions, reducing the need for frequent replacements and thus saving costs in the long run. Its compatibility with cable sizes from 2.5mm to 6mm offers flexibility, allowing for optimized cable usage and further cost savings.

The NSPV brand design guarantees quality, while the three available types—Cable Male, Cable Female, and Panel Male—simplify installation and maintenance. This versatility not only saves time but also reduces the need for multiple connector types, cutting down on inventory costs. Its straightforward operation and ease of inspection and repair make it a hassle-free solution, ensuring minimal downtime and maximum productivity for your solar PV system.

Product Specifications

Material	Constructed from high-quality PPE/PA materials, the connector offers excellent durability and resistance to environmental factors such as UV radiation, chemicals, and extreme temperatures.
Cable Size Compatibility	The connector is compatible with cable sizes ranging from 2.5mm to 6mm, providing flexibility in installation and system design.
Brand Design	The NSPV brand design ensures a sleek and professional appearance, while also guaranteeing high-quality manufacturing standards.
Types Available	The connector comes in three different types: Cable Male, Cable Female, and Panel Male, catering to various connection needs within a solar PV system.

Our Features

The NSPV 5C Solar AC Connector 5 Pins is a high-performance electrical connector designed specifically for solar energy systems. It boasts an IP67 rating, ensuring robust protection against dust and water ingress, making it ideal for outdoor installations. This connector supports a maximum rated current of 35A with a cable cross-section of 6sqmm, and a rated voltage of 500V AC, providing reliable power transmission in solar photovoltaic (PV) applications. Its typical contact resistance is ≤0.25 mΩ, ensuring minimal power loss and optimal efficiency.

Our Advantages

Five-Pins Design: Offers 5 pins for enhanced connectivity and flexibility in solar systems.
High Rated Current: Supports a maximum current of 40A (for 6sqmm cables), ensuring efficient power transmission.
High Rated Voltage: Rated for 500V AC, suitable for a wide range of solar applications.
IP67 Waterproof Protection: Provides excellent protection against dust and water, ensuring durability in harsh environments.
Wide Cable Compatibility: Suitable for cable cross-sections from 1.5~6sqmm or 16~10AWG, offering versatility in installation.
AC 5C Connector I Version: Features the latest connector version for reliable and safe solar power connections.

Application

The NSPV 5C Solar AC Connector 5 Pins is widely used in residential, commercial, and industrial solar PV installations. It is suitable for connecting solar panels, inverters, and other electrical components within the system, ensuring reliable and efficient power transmission.

FAQ

What is the maximum current rating of the NSPV 5C Solar AC Connector 5 Pins?

The maximum current rating is 35A with a 6sqmm cable cross-section.

Can this connector be used in wet or dusty environments?

Yes, the connector has an IP67 rating, making it suitable for use in wet and dusty environments.

What types of connectors are available?

The connector comes in three types: Cable Male, Cable Female, and Panel Male, to accommodate different connection needs.

What is the typical contact resistance of this connector?

The typical contact resistance is ≤0.25 mΩ, ensuring minimal power loss.

Is the NSPV 5C Solar AC Connector 5 Pins compatible with different cable sizes?

Yes, it is compatible with cable sizes ranging from 2.5mm to 6mm, providing flexibility in installation.
